Fractal Design ERA (M-ITX) MINI TOWER CARBON Cabinet FD-CA-ERA-ITX-BK

Era is a unique and elegantly understated feat of both design and technical engineering ŰÓ a compact chassis free from the excessive restrictions traditionally associated with small form factor systems.

Compact, uniquely designed aluminum exterior available in five colors
Stylish color-coordinated top panel
Supports dual slot graphics cards up to 295 mm in length

Small footprint. Big impact.

Look closer

Dont let the size fool you. This uniquely designed SFF case supports professional grade hardware thanks to a remarkably versatile interior. As space efficient as it is flexible, the Era comes with a sleek aluminum exterior and is available in five colors.

Just add water

The removable radiator bracket allows 240 mm or dual 120 mm radiators for robust liquid cooling.

Flexible storage

The two included storage brackets each support a single 3.5 HDD or two 2.5 SSDs.

Airflow and the Era

Efficient chimney design optimizes airflow across five total fan positions
Pre-installed 80 mm Fractal Design SSR3 fan exhausts heat silently and effectively
Easy-to-clean, high airflow nylon filters on the top, sides and base

SFX or ATX? Yes.

Our innovative adjustable brackets give you total flexibility with PSU mounting height in order to maximize effective use of interior space.

Need more air?

The color-coordinated wood and tempered glass top inserts are easily swappable with the included steel mesh panel for increased airflow.

Front Type-C

USB 3.1 Gen 2 Type-C with support for fast charging and speeds up to 10Gbps

Easy access

A magnetic top panel and tool-less latching side panels make for near-effortless maintenance

Large GPU Support

Allows dual slot graphics cards up to 295 mm in length

Specification :

Product Code FD-CA-ERA-ITX-BK
3.5/2.5 Universal drive brackets SFX PSU: 2 HDDs or 1 HDD + 2 SSDs; ATX PSU: 1 HDD
Dedicated 2.5 drive brackets SFX PSU: 4 SSDs or 2 SSDs + 1 HDD; ATX PSU: 2 SSDs
5.25 drive mounts N/A
Expansion slots 2
Front ports 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 3.5 mm CTIA combined audio/mic
Total fan mounts 5
Top fan 2x 120 mm
Rear fan 1x 80 mm (1 x SSR3 80 mm included)
Bottom fan 2x 140 mm (without 2-slot GPU)
Dust filters Bottom intake, Side intakes, Top exhaust
Fixed velcro straps Yes
Tool-less push-to-lock Both side panels
Left side panel Aluminum
Right side panel Aluminum
Compatibility
Power supply type ATX, SFX-L, SFX
Motherboard compatibility ITX
PSU max length 200 mm
Top radiator 120/240 mm or 2x 120 mm (max 125 mm width, 67 mm thickness w/ fans, dependent on PSU position/type)
GPU max length 295 mm or 210/190 mm (with low-mounted SFX/ATX PSU)
CPU cooler max height 120 mm (70 mm recommended with side-mounted 3.5 HDD)
Dimensions
Case dimensions (LxWxH) 325 x 166 x 310 mm
Case dimensions w feet/protrusions/screws 325 x 166 x 307 mm
Net weight 3.970 kg
Package dimensions (LxWxH) 385 x 240 x 420 mm
Gross weight 4.930 kg
Volume 16 liters
Warranty 2 Years
